[Salient Features]
Gas turbine driven generators are similar to steam turbine driven generators except that the machines have to be compact to be suitable for package assemblies. The generator can either be SPDP or water cooled air cooler mounted type.
| Synchronous Generators up to 65000KVA | |
|---|---|
| Voltage - 415, 3300, 6600, 11000, 13800, 15000Volts | |
| Cylindrical Rotor | |
| GVPI (Global Vacuum Pressure Impregnation) | |
| Insulation Class F | |
| Rated Speed - 1500 rpm / 1800 rpm | |
| Frequency 50Hz / 60Hz | |
| Bracket Mounted Forced Lubricating sleeve bearings , Single / Double bearing | |
| Totally Enclosed IP 54 with water cooled air coolers (CACW)/(CACA) | |
| Dedicated Jacking oil systems for larger generators | |
| Applicable standards - IEC, IS and JEC | |
| Mounted on common base frame | |
| Digital / Analog AVR | |
| Good Voltage regulation +/-0.5% | |
| Optional | PMG Excitation , Flanged shaft , Shaft vibration measurement Slip rings for rotor earth fault detection Any special voltage, frequency, transformer testing and motor testing generators, retrofit can be designed and manufactured based on Customer's requirements. |
